Go to Routing - VLAN - VLAN Static Routing Wizard.Log in to the management page of the switch.The switch routes traffic between VLANs, from the devices in VLANs 10, 20 & 30 to the internet gateway and back.īelow is a simple diagram presenting an overview of the network. In this example, the internet gateway is not configured to be VLAN aware. The devices in each VLAN access the internet through the internet gateway which is connected in VLAN 10.
This inter-VLAN communication can be restricted through the use of optional access control lists or ACLs (described later in this article). The devices in each VLAN are allowed to communicate with devices in other VLANs because routing is enabled on the switch. In this example, there are three VLANs configured on the switch: Note: The steps and screenshots in this article apply to NETGEAR managed switches running firmware version 11 and above. This article describes how to configure routing VLANs on a NETGEAR managed switch with shared access to the internet.
